Mechanical equipment of buildings; a reference book for engineers and architects (1916)
Harding, Louis Allen, Willard, Arthur C. (Arthur Cutts), 1878-1960 · New York Wiley · leaf 528
Fig. 30. Offset Corner Valvewith Male Union, Right Hand: Fig. 29. Steam Radiator Valve—Angle Pattern (Jenkins Bros.). Description of Parts. WheelLock NutSpindleBonnetDisc Holder 6. Disc 7. Waste Nut 8. Wheel Nut 9. Disc Nut10. Body 11. Union Nut 12. Union Nipple 13. Bottom Plate 14. Wood Wheel 15.…Building · Heating · Ventilation
Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
