Mechanical equipment of buildings; a reference book for engineers and architects (1916)
Harding, Louis Allen, Willard, Arthur C. (Arthur Cutts), 1878-1960 · New York Wiley · leaf 171
, and the regulator will operate the tilting draft door on theashpit. The chains should never be disconnected from the doors, and any adjustment of pressuresshould be regulated by moving the weight, B, on the lever. From fulcrum. A, to end of lever,D, should never be less than 18 inches. The… … Fig. 25. Steam Gage. and outlet will apply equally to the single inlet type, which latter is made up for only one tem-perature range. This instrument is placed on the boiler or heater and automatically adjusts the dampersaccording to changes in water temperature. The water circulates through the…
Building · Heating · Ventilation
