ng. A gravity circulating hot-water system,supplying both overhead and underfeed mains with an auxiliary pump and motor is shown inFigs. 23 and 24. This building, the Public Library of Brookhne, Mass., is heated throughoutby direct radiation, supplemented by indirect heaters for the book room and… … Fig. 24. fan takes its air from the top of the building through two down-takes, one at each side of themain entrance as shown on first-floor plan. The right and left wing are vented through roof asshown, and the former is equipped with a vertical shaft disc, fan of the propeller type. The 7 heating…
