in detail drawingof same. CHAPTER XIV WARM-AIR FURNACE HEATING ESSENTIAL FEATURES OF THE SYSTEM The method of warming or heating a building by what is generally known as a warm-airfurnace is termed furnace heating. The Furnace and Its Location. The furnace consists briefly of a cast-iron or steel… … Fig. 1. a double wall galvanized sheet steel jacket (Fig. 1 and 3), although biick is sometimes used in-stead of the steel jacket for this purpose. (Fig. 2.) Furnaces for soft coal (Fig. 3) are usually designed with a secondary air supply or over-draft for admitting heated air just at the surface…
