Mechanical equipment of buildings; a reference book for engineers and architects (1916)
Harding, Louis Allen, Willard, Arthur C. (Arthur Cutts), 1878-1960 · New York Wiley · leaf 374
t, usually HOT RLAST HEATING 355 No. 22 or 24 U. S. S. gage, which is connected to the fan either on the suction or discharge side.See types of heater jackets, Fig. 8, and dimensions of casings for pipe coil heaters, Fig. 16. Fig. .54 shows a complete assembly of this type of heater. The first… … Fig. 11. Pipe Coil Heater Base.(American Blower Co.) partition, the supply side being connected into the main return through a water sealed drip loopto prevent blowing live .steam into the main return, which is connected to a steam trap in theu.sual mannei-. Owing to the difference in pre.ssure…
Building · Heating · Ventilation
