Mechanical equipment of buildings; a reference book for engineers and architects (1916)

Harding, Louis Allen, Willard, Arthur C. (Arthur Cutts), 1878-1960 · New York Wiley · leaf 57

An illustration from Mechanical equipment of buildings; a reference book for engineers and architects, 1916, leaf 57 — the Pitot tube. The methotlemploying the Pitot tul)e is fuUj- described under the chapter on Hot Blast Heating. The Orifice Method. The discharge from the compressor or fan is piped to a gauging boxsimilar in construction to the one shown in Fig. 23. The opposite end of the box is provided

Building · Heating · Ventilation

Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
