Mechanical equipment of buildings; a reference book for engineers and architects (1916)
Harding, Louis Allen, Willard, Arthur C. (Arthur Cutts), 1878-1960 · New York Wiley · leaf 536
Fig. 30. Offset Corner ValveWTTH Male Union, Right Hand. Fig. 29. Steam Radiator Valve—Angle Pattern(Jenkins Bros.). Description of Parts. 1. Wheel 2. Lock Nut 3. Spindle 4. Bonnet 6. Disc 7. Waste Nut 8. Wheel Nut 9. Disc Nut 5. Disc Holder 10. Body 11. Union Nut 12. Union Nipple 13. Bottom Plate…Building · Heating · Ventilation
Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
