Mechanical laboratory methods; the testing of instruments and machines in the mechanical engineering laboratory and in practice (1922)

Smallwood, Julian Chase · New York, D. Van Nostrand company · leaf 45

An illustration from Mechanical laboratory methods; the testing of instruments and machines in the mechanical engineering laboratory and in practice, 1922, leaf 45 — Fig. 14.—Mechanism ofPressure Recorder. 4. Draft Gage CalibrationPrinciples. Draft gages are generally special forms of manom-eters used to measure the reduced pressure (less than atmosphere)in chimneys, which creates the draft. This is expressed in inchesof water and, as it is usually only a few… … 28 SCALES AND PRESSURE GAGES 4 U-tube will not do. Fig. 15 shows a favored type. It is the ordi-nary manometer with one leg on a slant, so that the travel of thePi « level of the liquid used is magnified. ~H In use, the instrument should be settrue to its designed level and theliquid adjusted so…

Mechanical engineering
