Mechanical laboratory methods; the testing of instruments and machines in the mechanical engineering laboratory and in practice (1922)

Smallwood, Julian Chase · New York, D. Van Nostrand company · leaf 53

An illustration from Mechanical laboratory methods; the testing of instruments and machines in the mechanical engineering laboratory and in practice, 1922, leaf 53 — Fia. 21.—Rope Brake. … Torque = OS - Brake Zero) R Fig. 22—Rope Brakes mrm/r/rrrmmTorque = (W-S-w) R sufficient to feed the water at a rate just equal to the loss bysteaming. Hydraulic friction brakes are the same as those just describedin principle though quite different in detail. A series of discsmounted on the power…
