tions a and h. Thus, if V and y are the velocities in feet per second, and H and h thepressures in feet of waterat the sections a and 6,respectively, and W theweight of water passingper second, then g being the acceleration of gravity. Wealso have the relation 7 _ Area at b_ dPV Area at a D^… … Fig. 61.—Venturi Meter. from which the cubic feet per second discharged under idealconditions is Q = area X velocity Owing to friction losses the discharge thus calculated is too high.To allow for this, a coefficient of discharge, C, less than unity,is introduced. Combining V 2^ and 0.7854, for…
