Mechanical laboratory methods; a testing of instruments and machines in the mechanical engineering laboratory and in practice (1918)

Smallwood, Julian Chase · New York, D. Van Nostrand company · leaf 211

An illustration from Mechanical laboratory methods; a testing of instruments and machines in the mechanical engineering laboratory and in practice, 1918, leaf 211 — ette with water fromthe bottle B, The right leg of the pipette is completely filledwith reagent just before the gas enters; the gas displaces it intothe left leg. Rubber bags, /?, seal the left legs of the pipettes 190 PRODUCTS OF COMBUSTION 40 so that the reagents will not deteriorate through… … *Jm/m//////////////////^^^>r^ Fig. 81.—Gas SamplingBottle. To F

Mechanical engineering laboratories

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
