321. TRAMMEL CRANK.—The pins c, c onthe rod B traverse the two right-angled slots in therevolving face plate, producing a reciprocating motionof the rod B. 90 STEAM POWER. … 322. CRANK-PIN LUBRICATOR.—The oil cup is fixed. A wiper on the con-necting rod end takes off the drop of oilfrom the capillary feed oil cup.
