Mechanical movements, powers and devices (1911)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 104

An illustration from Mechanical movements, powers and devices, 1911, leaf 104 — 2,z6. « SMITH ROTARY ENGINE.— Four arms with cylindrical sectors are rotatedaround an axis central to a perforated cylindricalshell. The driven shaft and head discs are ec-centric to the shell. The pressure of steam be-tween the wings tends to push them apart, bywhich the differential leverage on… … 337. BERRENBERG ROTARYENGINE.—Two intersecting cylindricalshells. The steam cylinder D has twocylindrical pistons, D, D, on oppositesides, that mesh in corresponding cavi- ^=, ties in the cylindrical steam valve, both rotating in unison by equal external gearing. The steam port passesthrough the…
