Mechanical movements, powers and devices (1911)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 145

An illustration from Mechanical movements, powers and devices, 1911, leaf 145 — e%m^^m volume of water to a height ofnearly half their diameter. 480. PERSIAN WHEEL.—A current-driven water lift; used in Eastern countries.A hollow shaft, with curved arms and floats,with buckets susjDended at their periphery.The current carries the floats forward, fillingthe buckets and at the… … HYDRAULIC POWER AND DEVICES. i3i

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
