Mechanical movements, powers and devices (1911)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 329

An illustration from Mechanical movements, powers and devices, 1911, leaf 329 — 1294. UNIVERSALshafting. Ring gimbaL JOINT, for … 1295. HOOKES UNIVERSAL JOINT.—One shaft end is keyed into a ball with trun-nions, which turn in a ring with trunnions at 1:^:1 I right angles with the ball trunnions. The ringtrunnions turn in the outer shell to which theother shaft is keyed. MILL AND FACTORY APPLIANCES. 319

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
