WHITWORTH THREAD !/ … 1399. SCREW THREADS.—UnitedStates Standard Thread. Flat top andbottom. Depth equals 0.65 of the pitch.Angle 60°. 1400. SCREW THREADS, Whit-worth thread. Rounded top and bot-tom. Depth equals 0.75 of the pitch.Angle 55°. TRAPEZOIDAL ^t-jxTHREAD I I
