Mechanical movements, powers and devices (1911)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 387

An illustration from Mechanical movements, powers and devices, 1911, leaf 387 — 1556. LAPIDARY OR LITHOLOGICALLATHE for amateur work. A vertical spindlewith disc lap of lead, driven by a bevel gear andcranks, through a vertical shaft pulley and belt.A splitting disc and spindle are also driven fromthe main pulley. 1557 … . WIRE-DRAWING MACHINE. a^ the reel. 3, draw plate. <r, power drum, operated by gearbeneath the bench. When the wireis all wound on the drum it ischanged to the reel and drawn ina reverse direction.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
