Mechanical movements, powers and devices (1911)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 70

An illustration from Mechanical movements, powers and devices, 1911, leaf 70 — ECLIPSE RETURN TUBULARMARINE BOILER—All thefire-box, back chamber, directand return tube surface, divid-ed by 12, equals boiler horse-power. STEAM POWER. 59 … SMOKl OUTLET
