Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 112
RUDEOIL BURNER. Gives a broad flame. A, oil supply; B, steam supply; C,mixing chamber. E, steam chamber connecting withsteam ducts G, H, I. K, K, steel plates which can be re-newed when worked out. J, set screw. Gives a broad and powerful flamefor boiler furnaces. 371c. PETROLEUM FUR-NACE.—For the… … agitatorfeed-wheel\ AGITATOR SECTOR.SHEATH-NUT- SHEATHLOCK-NUTS. coking takes place andthe coal passed on tothe inclined rockinggrate. 37it/. AUTOMOBILE BOIL-ER.—A baffle plate above thewater line at the riveted jointprevents foaming or splashing ofthe water into the steam pipe bythe vibration of…
Mechanical movements
