sidepassage at the opening of thecylinder port at the end ofthe down stroke of the piston. E, clearance space; B, guard on pis-ton ; A, crank chamber ; F, tube igniter; D, O, inlet valves. MOTIVE POWER. 121 433. STREET RAILWAY GASMOTOR PASSENGERCAR, German model. Themotor consists of two cylin-ders… … runs continually.car floor. Compressed gas is stored in cylinders under the
