Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 407
1647 MAUSER RIFLE.—Magazine in theforestock. The slid-ing breech blockencloses the firingspring plunger andraises the cartridgelever A. 396 MISCELLANEOUS DEVICES. 1648. WINCHESTER MAGAZINE RIFLE.— The breech lock slidesin line with the barrelby a toggle link, oper-ated by the breech le-ver, which…
Mechanical movements
