63. ROPE TRANS-MISSION to a movableshaft at right anglesfrom the driving-shaft, MOVtBLC . si^^^with tension slide andweight. … 64. VERTICAL TENSION with slides and pulley guide. CARRIAGE, 32 TRANSMISSION OF POWER. ^— ^ r n r r ■ 4« ■
