and a small pulleyQi, moving freely on the shaft E. AtQ2 another small pulley is fixed to shaft E. The tension of trans-mission displaces the relative position of the small pulleys and throughan endless belt draws the loops F and G farther apart, which by pul-leys and index not shown indicates the… … tion of levers ; W, weight.
