Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 127

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 127
421 d. AIR COOLING TOWER.—Forcooling the water of a surface condenser.The hot water is forced to the top of thetower and distributed over a large surfaceof tile through which air is circulated bythe large fan at the bottom of the tower.The water much cooled drips to the tankbelow from which it is… … 421^. FLEXIBLE METALLICHOSE.—The joints are packedwith rubber, which lies between theoverlapping edges of the corru-gated tape forming the screw.
