465. OVERSHOT WATER WHEEL—Power equals about sixty per cent, of the valueof the water-fall flowing over the wheel. 466. IRON OVERSHOTWHEEL.—The frame and buck-ets are made of iron or steel.The lightest wheel of its kind. Leffel model. 467. Front view. 132 HYDRAULIC POWER AND DEVICES. … 468. UNDERSHOT WATER WHEEL.—Power equals about forty per cent, of the valueof the water-fall flowing under the gate.
