Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 153

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 153
517. LIFT PUMP.—The limit of water lift inthis pump is about thirty feet, but practically abouttwenty-five feet is its available working height. … 518. DOUBLE-LANTERN BELLOWS PUMPOR BLOWER.—A very ancient device for waterand for a blower of air for forges. Will make aconstant blast by using one side as a receiver, dis-pensing with the valves and connection on receiverside.
