Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 166
REVERSIBLE FILTER.—The positionof the filter in the cut is for filter-ing downward. By turning it overon the trunnions it can be cleanedfrom above downward, whichclears it of all sediment. The in-flow is from above and the wasteis through the trunnions to thesewer while cleaning. … 575-TERN FILTERING CIS- , plan. 576. Section. The pump pipeextends to the bottom of thecistern and across, with lateralbranches. The pipes on the bot-tom to be perforated with one-sixteenth inch holes, enough to give a free flow of water to the pumps.Cover the pipes with sifted gravel larger than…
Mechanical movements
