602. DRIVEN WELL.—A clamp stronglybolted to the well pipe on which the weightstrikes to drive the tube. A clamp and twosheaves are bolted at the top of the tube withropes rove through the sheave blocks and madefast to the weight for raising it. The weight ishollow, and rides loosely over the tube.… … 603. AUTOMATIC FLUSH SEWERTANK, Miller model. In this form thesiphon is inverted, holding the water seal tobalance the water head in the tank in theuptake of the siphon. The cap over thelong end of the siphon is to seal the air inthe siphon until the sewage pressure isequal to the water-balanced…
