B 1 A P L L \ Jj \l^Si f^^3 N^^j/ 609. CHAPMAN ASPIRATOR orvacuum pump. A water ejector in which thepropelling power may be derived from a faucetof any town water-works, or a tank having ahead of seventeen feet, equal to one-half thestatic water-head of a vacuum. Water entersat the conical end.… … 610. HYDRAULICor elevator. Sectionplunger and sheaves. LIFT for a crane showing cylinder 611. Plan, showing position of valvechamber and valve lever in three directionsfor stop, start, and reverse. The side rodlimits the extreme movement of the plungerby automatically operating the valve lever.…
