Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 209

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 209
741. LUMINOUS FOUNTAIN.—The lower endof the jet nozzle is fitted with a strong disc of plateglass. A concave mirror, placed in the focus of an arclight just below the glass disc, brilliantly illuminatesthe water jet. 198 ELECTRIC POWER AND CONSTRUCTION. … 742. ELECTRIC HEATER.—Coils of German silver wirewound around asbestos cords and rove over porcelain buttons forinsulation. The buttons may be fastened to a frame of any requiredform. <1ZI[>=^X 743. ELECTRIC SOL-DERING COPPER.— The copper is wound witha coil of resisting material; platinum…
