Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 210

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 210
745. ELECTRIC SEARCHLIGHT,Edison model. An arc light in front ofand in the focus of a concave reflector.It gives a beam of light nearly parallel.The front of the case has a plane glassfor protection. It swivels in all direc-tions. ELECTRIC POWER AND CONSTRUCTION. 199 … 746. ELECTRIC FURNACE, show-ing the recess and flat crucible. Elec-trodes of hard carbon and connections. 747. OPEN TOP ELECTRICFURNACE.—A cavity in a box of re-fractory material with holes on eachside through which the insulated car-bon electrodes are inserted. SIEMENS ELECTRIC GASFURNACE.—Gas…
