Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 228

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 228
-.-li:r:r:l-l:l ^^ 836. THRUST BEARING for a pro-peller shaft. The collar brasses are set inmortices in the frame ; they are made inhalves and bolted together. … 837. SILVERS MARINEGOVERNOR.—The two pairof balls are pivoted to the re-volving shaft at the centre oftheir connecting arms. Theircentrifugal tension is held andadjusted by the helical springI, and thumb-screw. The open-ing of the bails moves the sleeve, D, for controlling the valve gear.

Mechanical movements
