846. ROAD MACHINE,for scraping and levellingcommon roads. 847. REVERSIBLE ROADROLLER.—The tongue is at-tached to the frame that carriesthe drivers seat, and is bal-anced by the weight on therear arm. By unlocking thecatch the horses wheel aroundthe roller with the tongue andseat frame, and the… … 848. ROAD ROLLER.—Steam. driven. One of the heavy classnow improving our roads. 849. SINGLE ECCENTRIC R&VERSING GEAR.—Used on tractionengines. A is a wheel keyed on thecrank shaft; D is the eccentric; C, alink; B, B, bell crank, connected tosleeve and eccentric. The movementof the sleeve E by…
