Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 271

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 271
cording to the length of the concentric portionof the cam. 1035. TRIANGULAR ECCENTRIC forproducing a stop motion at each half-revolutionof the face plate a, by the proportional peripherallength of the outer curve of the triangular cam.Used on a French engine. 1036. RECIPROCATING MOTION with… … 1037. UNIFORM RECIPROCATING MO-TION from the circular motion of a crank or discwrist pin. The endless groove in the cross head ismade to conform in shape to the varying rectilinearmotion of the wrist pin. 1038. NEEDLE-BAR SLOT CAM, for sew-ing-machines. The depression in the pin slotgives the…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
