Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 304

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 304
HOROLOGICAL. 293 … 1193. PIN-GEARED WATCH STOP. —Thewinding stops at the convex tooth of the stop. 1194. WATCH TRAIN. rt, key stem. b, barrel and spring. Cy e, h, /, pinions. d, h, spur wheels. /, /, pallets and escapement. k, lever and balance wheel. 1194a. EQUATED SUNDIAL.—The curved bulbs onthe shadow stile are…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
