Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 307

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 307
face of the dialto be placed parallel with theequator, as shown by the indexof the latitude. The range ofthe stile and the 12-hour markto be on the meridian. The inner hour circle figur-ing is reversed so that by in-verting the dial the summermorning and evening timemay be observed. 1194/z. NEW… … Section XIV MINING. Quarrying, Ventilation, Hoisting, Conveying, Pulverizing, Separating,Roasting, Excavating, and Dredging.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
