Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 320

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 320
1252. ORE ROASTINGFURNACE, revolving type.The large cylinder takescharge by the manholes, andrevolves on power-driven rol-lers. The furnace is on atruck to be removed whenrequired. The heated gases pass through the revolving cylinder and to a chimney, MINING. 309 … 1253. RAILWAY EXCAVATOR, the Otis pattern. 1254. RAILWAY STEAMSHOVEL, the Victor model.For excavating railway cuts, or gen-eral work on temporary rails. 1255. CONTINUOUS DITCHINGDREDGE. — Discharging overheadon the banks by a carrier from underthe bucket discharge.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
