Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 322

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 322
i2596\ HAND POWER ROCKDRILL, Jackson model.—A power-ful helical spring drives the drillforward. The crank operates a camwiper for drawing back the drill;the motion is regulated by the flywheel. … 1259^. FREE RUN-NING AXLES for miningcars. The divided axle heldtogether by grooved bear-ings, makes a light runningcar on the small curves inmines.

Mechanical movements
