Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 341

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 341
1358. PORTABLE DRILL, rope trans,mission and flexible shaft. One continuousrope over driving pulley, two double sheavesanchored, and flexible shaft pulley; allow-ing the driving sheave of the flexible shaftto be anchored in any position, and forlightening the driving rope. 1359. MULTIPLE DRILLING… … 1360. MULTIPLE DRIL-LING MACHINE.—For drill-ing a number of holes in flangesat one time. The drill chucksare adjusted in a spider for anysize circle and connected to thedriving head with jointed rods.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
