Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 356

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 356
1438. COP WINDER.—The cop tube on thespindle revolves. The arm with an eye, carriesthe thread forward and backward on the cop. MILL AND FACTORY APPLIANCES. 345 1439. BOBBIN WINDER.—The flyer revolves, whilethe bobbin is moved up and down the spindle for evenwinding. Thread passes through the hollow… … 1441 KNITTING MACHINE, auto-matic ri3 knitter, Heginbotham model.Vertical needles and two bobbins. 1442. KNITTING MACHINE,seamless knitter, Bellis &Weinanmayer model. Verti-cal needles. 346 MILL AND FACTORY APPLIANCES.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
