Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 359

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 359
1443^. STEAM VULCANIZERfor repairing bicycle tires.—Two steamslabs and tightening screw set on asmall boiler heated by a lamp or torch;steam pressure should be 75 lbs. persquare inch. Small clamps and screwsare attached to the top steam box forvulcanizing other articles. The lowersection is the… … 1443/. STEA^I VUL-CANIZER for repairingbicycle tires and bands.—The cast iron bed piece ishollow to hold sufficientwater for making steam,which should be at 75pounds pressure. Com-pression is made by thelever and weight for bothtires and bands. A gas orgasoline torch for heating.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
