Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 362

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 362
1450. HYDRAULIC SAND EJECTOR A thin annular jet of water, under high pressure,will eject sand and water from a sump and dis-charge at an elevation. The principle of the Eads ejector dischargings and from the caissonsof the St. Louis Bridge. 1451. TOGGLE STUMP PULLER. —By pulling up the two toggle… … 1452. RIGHT-AND LEFT-HANDTURNBUCKLE, sleeve and yoke pat- tern. 1453. SWIVEL SHACKLE.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
