Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 362

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 362
1452. RIGHT-AND LEFT-HANDTURNBUCKLE, sleeve and yoke pat- tern. 1453. SWIVEL SHACKLE. … 1454. SLIP HOOK, for drop weights andtemporary pile hammer. 1455. TRIP HOOK.—A split shank withtongue and catch pivoted between the sides ofthe shank as shown. 1456. BALANCED RIVETINGMACHINE on a truck. For yardservice, and iron and steel structuralwork. 1457. RELEASING GRIP of a pile-driving…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
