An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 369
1496. BRIDGE TRUSSES.— The McCallum inflexiblearched truss. A woodenbridge. 1497. Howe truss, withinclined end posts, verticalstruts and bi-panel tie rods. 1498. Post truss, verti-cal end posts with inclinedstruts from each end meet-ing at the centre.
