1550. MICROMETER SCREW ADJUSTMENT.— The tangent arm is made fast or loose on the shaft bythe spring dip and screw. Used mostly on theodo-lites and transit instruments. 1551. CORRECT PRINCIPLE in setting a hot-water house boiler. H, E, circulating pipes. B, water-back or coil. K, draw-off. D,… … 1552. UNDER-FEED HEAT-ING FURNACE, Colton-Smeadmodel. A smokeless furnace forhouse heating with bituminous coal.A plunger is operated by a leversector and rack to push the coalbeneath the fire.
