Mechanical movements, powers, devices and appliances (1901)
Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley & company · leaf 133
443. GOVERNOR AND VARIABLE CAMfor a gas engine. The centrifugal movementof the governor balls slides the sleeve on thegovernor shaft, and also the variable camsleeve, a, on the driving shaft, by the bell-cranklever, e. The disc roller, I?, on an arm of a rockshaft, rolls upon one or the other cams… … 444. INLET VALVE for gas engine.A valve disc slightly held in contact withthe seat by the spring. Air holes should b^drilled close together around the valve seat,so that combined air area shall be largerthan the area of the gas inlet.
Mechanical movements
