Mechanical movements, powers, devices and appliances (1901)
Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley & company · leaf 242
^-^ … 904. CONTINUOUS ROTARY MOTION of a pinion producing reciprocating motion of thedouble-geared wheel carrying drum of a mangle.The slotted stand allows the pinion shaft to riseand fall, its end guided by the slot in the return-gear wheel to give the mangle drum a quickreturn. 905. MANGLE WHEEL with…
Mechanical movements
