Mechanical movements, powers, devices and appliances (1901)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley & company · leaf 323

An illustration from Mechanical movements, powers, devices and appliances, 1901, leaf 323 — 1265. ADJUSTABLE POST HANGER. 1266. ADJUSTABLE FLOOR STAND, shaft bearing. 1267. CONTINUOUS TRAVERSINGROLLER or ball bearing for an axle. 1268. ROLLER WHEEL ANTLFRICTIONBEARING. 1269. BALL BEARINGS in anadjustable journal box. Aloosesleeve is inserted betweenthe balls and the shaftto prevent wear… … 1270. Longitudinal section. MILL AND FACTORY APPLIANCES. 315

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
