Mechanical movements, powers, devices and appliances (1901)
Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley & company · leaf 366
DECK BRIDGE TRUSSES. i486. Single strut deck truss for shortspans, 30 to 40 feet. 148 7. Double strut deck trussfor 50 to 70 feet span, 1488. Multi-ple strut decktruss for 100feet span. 1489. BRIDGE TRUSS.—Inclined strut and tie rod for eachpanel,with stiff compression upperchord. Vertical members…Mechanical movements
