Mechanical movements, powers, devices and appliances (1901)
Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley & company · leaf 373
c fNSSSWSi 0 I5I9. :i GREAT CURVE DELINEA-TOR. — Thin-edgedr=^ discs of different diameters are attachedto a bar or tube at adistance apart, so thattheir relative diam-ters and distance will correspond to the required radius, which maybe computed by the difference in diameter multiplied by the… … 1520. CONCHOID DELINEATOR,of Nicomedes. A slotted head T-piece,A, B; a slotted arm, G H, with traversepin at F. Distance between F, H, andpin at E may be variable to suit therequired condition of curve. Pencil atH delineates a conchoidal curve, usedin architectural drawings for the linesof columns.…
